A2CD0120 24VDC RGBW 4- In-1 LED Outdoor LED Underground Lights, RGBW LED Exterior Inground Lighting

A2CD0120 24VDC RGBW 4- In-1 LED Outdoor LED Underground Lights, RGBW LED Exterior Inground Lighting

MOQ: 10pcs
Standard Packaging: Inner box and outer carton
Delivery Period: 5~15 working days
Payment Method: T/T, L/C, Western Union, MoneyGram
Supply Capacity: 100,000 pcs per month
Detail Information
Place of Origin
Guangdong China
Brand Name
COMI LIGHTING
Certification
CE, ROHS
Model Number
A2CD0120
Item Type:
4 In 1 RGBW LED Inground Light
LED Brand:
Cree, Or Edison
LED Type:
4-in-1 RGBW LED
Power:
4~6W
Working Voltage:
24VDC
Front Ring:
Stainless Steel SUS 316L#
Housing:
Die-casting Aluminum
IP And IK Rating:
IP67 And IK07
Minimum Order Quantity:
10pcs
Packaging Details:
Inner box and outer carton
Delivery Time:
5~15 working days
Payment Terms:
T/T, L/C, Western Union, MoneyGram
Supply Ability:
100,000 pcs per month
High Light:

led underground light

,

led buried light

Product Description

A2CD0120 24VDC 6W 4 - in- 1 RGBW 4 color mixing LED Inground Light Outdoor Rated IP67







Features and Benefits:

1. 4- in-1 RGBW 4 color mixing makes the light color more bright and blinding;

2. Hard chromeplated stainless steel SUS 316L# front ring and die-casting aluminum lamp housing;

3. 8mm thickness step tempered glass Light windown,2578KGs full area glass pressure capacity;

4. Outdoor rated IP67 design







Material speicification:

Housing: 12# Die-casting grey powder coated aluminum.
                T=60-80µm Adhesion of ISO class 1/ASTM class 4B
Front ring: Hard chromeplated stainless steel SUS 316L#
Light Window: Step tempered glass.T=8mm
Glass pressure capacity: Full area=2578kgs
Lens: Symmetrical optical lens, efficiency≥85%
Cable gland: IP-68 PG-9 PVC
Gasket: Molding shaped silicone seal
LED: Cree,or Edison federal RGBW 4in1 LED
LED Driver: Constant Voltage Input,Constant Current Output
Operating temperature: -20℃~40℃
Mounting sleeve: ABS 015#
Power cable: H05RN-F 5X0.5mm² L=0.5m




Technical Information:

Item No. Light source
Degree
(Θ 1 / 2 )
Input
voltage
(V)
Typical
operating
current (mA)
Typical
consumption
(w)
Typical
luminance
(lm)

IK

rate

A2CD0120 1×4W
RGBW 4in1
30°
24VDC
255
6
154
07



Notes:
1. Color options: Warm White, Neutral White, Cool White, Red, Green, Blue,RGB and etc;
2. Specification and availability are subjected to change without notice.
3. For more detail specification in PDF, please contact us separately.





Dimensional Drawing (Units:mm)


A2CD0120 24VDC RGBW 4- In-1 LED Outdoor LED Underground Lights, RGBW LED Exterior Inground Lighting 0



A2CD0120 24VDC RGBW 4- In-1 LED Outdoor LED Underground Lights, RGBW LED Exterior Inground Lighting 1
A2CD0120 24VDC RGBW 4- In-1 LED Outdoor LED Underground Lights, RGBW LED Exterior Inground Lighting 2
