LED Landscape Spot Lights Spike Mounting

LED Landscape Spot Lights Spike Mounting

MOQ: 10pcs
Standard Packaging: inner Box and Outer carton
Delivery Period: 3 - 15 Working Days
Payment Method: T/T, L/C, Western Union, MoneyGram
Supply Capacity: 100,000 pcs per month
Detail Information
Place of Origin
Guangdong China
Brand Name
COMI LIGHTING
Certification
CE, ROHS, ETL, ISO9001: 2008
Model Number
R3BQB0128S
Item Type:
COB LED Landscape Flood Lights
LED:
6W Or 10W COB LED
Power (W):
24V=9.8, 120V=10.5, 240V=10.5
Luminance (LM):
Cool White=685, Warm White=674
Material:
Aluminum Body And PVC Spike
Input Voltage(V):
24VDC, Or 110/240VAC
Optional Accessories:
Hood
Installation:
By Spike
IP Rating:
IP65
Warranty:
2 Years
Minimum Order Quantity:
10pcs
Packaging Details:
inner Box and Outer carton
Delivery Time:
3 - 15 Working Days
Payment Terms:
T/T, L/C, Western Union, MoneyGram
Supply Ability:
100,000 pcs per month
Highlight:

gu10 garden spike spotlights

,

led landscape flood lights

Product Description

R3BQB0128S 24V or 110 - 240V 1 * 10 W COB LED Landscape Flood Spot Lights Spike Mounting







Features and Benefits:
1. Vertical and horizontal direction angle adjustable;
2. Cree or BRIDGELUX COB type power LED as light source with high lumen output
3. IP65 design for outdoor lighting
4. Dimming control by DALI, PWM, 0 -10V

5. Optional accessories hood







Material specifications:

Housing
12 Die-casting grey powder coated aluminum .
T=60-80μm. Adhesion of ISO class 1/ASTM class 4B
Glass Tempered glass. T=4mm
Reflector Optical Reflector efficiency≥90%
Cable gland IP-68 PG-9 copper and nickel coated
Gasket Molding shaped silicone double seal
LED SHARP COB 10W
PCB Excellent heat conductivity aluminum, coefficient of Heat Conductivity≥2.0w/mk
Driver
Constant current output
Single color LED=1-circuit output
Operating temperature -20℃~40℃
Power cable
H05RN-F 2X1.0mm^2 L=2m (low voltage)
H05RN-F 3X1.0mm^2 L=2m (high voltage)
Spike PVC
Mounting base Powder coated die-casting aluminum









Technical Information:

Item No. Light source
Degree
(Θ 1 / 2 )
Input
voltage
(V)
Typical operating
current (mA)
Typical
consumption
(w)
Typical
luminance
(lm)

IK

rate

R3BQM0128S

(Round Base)

1×10W
SHARP COB
25
24VDC Or
120 /240
24V=411
120V=88
240V=48
24V=9.8
120V=10.5
240V=10.5
Cool white=685
Warm white=674
05

R3BQB0128S

(Spike)

1×10W
SHARP COB
25
24VDC
120/240
24V=411
120V=88
240V=48
24V=9.8
120V=10.5
240V=10.5
Cool white=685
Warm white=674
05
Note:
1. Color options: Warm White, Neutral White, Cool White, Red, Green, Blue,RGB and etc;
2. Specification and availability are subjected to change without notice.
3. For more detail specification in PDF, please contact us separately.



LED Landscape Spot Lights Spike Mounting 0LED Landscape Spot Lights Spike Mounting 1





LED Landscape Spot Lights Spike Mounting 2



LED Landscape Spot Lights Spike Mounting 3

LED Landscape Spot Lights Spike Mounting 4



LED Landscape Spot Lights Spike Mounting 5
