| MOQ: | 20pcs |
| Standard Packaging: | 4pcs/carton |
| Delivery Period: | 3-20days |
| Payment Method: | T/T, Western Union, L/C |
| Supply Capacity: | 100,000pcs per month |
IP66 Square Led Wall Washer Flood Lights For Outdoor Accent Lighting Or Landscape Lighting Or Architectual Lighting
1. In addition to the traditional control methods, this series of products can use touch screen control, and the internal algorithm realizes electronic focusing;
2. Achieve electronic zoom narrow, small, medium, and medium-large modular lens;
3, 4K high-speed feedback chip
4. Patent appearance design, double-layer fluorocarbon spraying process.
5.Password security lock for lamps
Installation: Integrated tilting, surface-mounting base allows easy installation on the ground, wall or ceiling; Max adjustment from the horizontal: -10º to +10º and vertical: -40º to +90º.
Technical Specifications:
| Item No. | Control Mode | Color | Light Source |
Beam Angle
(Θ1/2)(°)
|
Input Voltage |
Rated
Power
|
Luminous Flux
(lm)
|
IK Rate |
| B3ZD16075-X B3ZE16100-U |
CC, DALI, 0-10V
|
Single Color |
16pcs Cree
or Osram LED
|
2.5°, 4.5°, 8°, 12°,
20°, 30°, 45°, 60°,
10×70°, 5×20°
|
100-305VAC
50/60Hz
|
75W,
100W(U)
|
6300~10000LM | IK10 |
| B3ZE16100-X |
DMX512/
RDM
|
RGBW
4-in-1
Full Color
|
16pcs Cree
4-in-1 LED
|
8°, 15°, 20°,30°,
15×60°
|
36VDC, or
100-305VAC 50/60Hz
|
100W
|
3500~4000LM | IK10 |
| B3ZE16100-X |
DMX512/
RDM
|
RGBW
4-in-1
Full Color
|
16pcs Osram
4-in-1 LED
|
3.5° |
24VDC, or
100-305VAC
50/60Hz
|
100W
|
3500~4000LM | IK10 |
| B3ZE32075-X B3ZE32100-U |
CC, DALI, 0-10V
|
Single Color,
RGBW 4-in-1
Full Color
|
32pcs
Osram LED
|
6°, 15°, 20°,
30°, 45°,
20×40°, 15×25°
|
36VDC, or
100-305VAC
50/60Hz
|
75W,
100W(U)
|
6500~7500LM | IK10 |
| B3ZE32075-X |
DMX512/
RDM
|
RGBW
4-in-1
Full Color
|
32pcs
Osram LED
|
6°, 15°, 20°,
30°, 45°,
20×40°, 15×25°
|
36VDC, or
100-305VAC
50/60Hz
|
75W | 2500~2800LM | IK10 |
| Z3ZE64075-X |
Touch Panel/
Screen
|
Single Color |
64pcs
Cree LED
|
7～36°
Photoelectron
zoom
|
24VDC, or
100-305VAC
50/60Hz
|
75W | 6500~7500LM | IK10 |
| B3ZE0475-X |
DMX512/
RDM
|
Single Color |
4pcs
Cree COB LED
|
12° , 24° , 36° , 70° |
100-305VAC
50/60Hz
|
75W | 6500~7500LM | IK10 |
Notes:
1. (U) in rated power stands for "U-shape bracket model only";
2. Color: single color, tunable white, RGB, RGBW are available upon request.
3. Specifications are subjected to change without notice.
Item Number named method for best outdoor flood lights:
| B | 3 | Z | F | 25 | 75 | -X |
| Lens Type: B-Symmetrical Lens Z: 4-in-1 modular lens for Photoelectron zoom |
Series-3:
LED Architecture and |
Zoomdim Series | Code No. for lamp housing |
LED Quantity | Power of lighting fixture | Installation Mode/ Part (please view below) |
Zoomdim LED Flood light with various Optional Parts for installation (-X) to meet different applications:
| Picture |  |
 |
 |
 |
 |
 |
 |
| Name of Parts | Round base | U-shape Bracket | Spike (stake) | Dia. 48mm arm | Pole hoop | Screws fixed type base | Tree strap |
| Installation modes | Surface Mount on the ground, wall or Ceiling | Surface Mount on the ground, wall or Ceiling | On Ground mount by spike (stake) | Installed onto dia. 48mm pole arm | Pole Mount by hoop | Pole mount by screws fixed type base& screws | LED floodlight mount on tree or pole by strap. |
| Code No. for Parts | B | U | S | A | H | L | T |
Applications:
The LED flood lighting fixture is designed and suitable for outdoor lighting for park, hotel, villa, plaza, museum, stadium, sculpture, monument, tree, temple, church, mountain and etc.
|
|
