24VDC or 110~240VAC 0.5W Sqaure LED Inground Light Frosted Lens with Soft Beam

24VDC or 110~240VAC 0.5W Sqaure LED Inground Light Frosted Lens with Soft Beam

MOQ: 10pcs
Standard Packaging: Inner Box and Outer carton
Delivery Period: 3~15 working days
Payment Method: T/T, L/C, Western Union, MoneyGram
Supply Capacity: 100,000pcs per month
Detail Information
Place of Origin
Guangdong China
Brand Name
COMI LIGHTING (HK)
Certification
CE, ROHS, ISO9001: 2008
Model Number
D2CAR0607,D2CAR0315(RGB)
Item Name:
IP67 Soft Beam SMD LED Underground Light
Input Voltage:
24VDC, Or 110~240VAC
LED Brand:
Osram, Cree, Citizen, Samsung, Epistar
Light Source:
6pcs 2835SMD LED Or 3pcs 5050 RGB 3-in-1 LED
Power(W):
24V=0.3,120V=0.5, 240V=0.8W
Luminance(lm):
Cool White=13.7, Warm White=11.8
Front Cover:
Round Shape And Made Of Stainless Steel SUS 316L#
Lamp Housing:
Die-casting Aluminum
IP And IK Rating:
IP67 And IK09
Warranty:
2 Years
Minimum Order Quantity:
10pcs
Packaging Details:
Inner Box and Outer carton
Delivery Time:
3~15 working days
Payment Terms:
T/T, L/C, Western Union, MoneyGram
Supply Ability:
100,000pcs per month
High Light:

led underground light

,

led buried light

Product Description

D2CAR0607, D2CAR0315 (RGB) 24VDC or 110~240VAC 0.5W 0.8W Frosted or Milky Lens SMD LED Inground Light with Soft Beam Output​ and Round Front Ring







Features and Benefits:

1. Uses SMD LED as light source with low power consumption, cost saving;

2. Front cover is made of Stainless steel SUS 316L# and Full area=783kgs Glass pressure capacity;

3. Single color or RGB 3-in-1 full Color options

4. High quality or UL Listed LED driver;

5. Milky/ Frosted/ White print glass make the lighting fixture with soft beam output;

6. IP67 waterproof and IK09 which enables the LED underground light be widely used in many indoor or outdoor lighting application;

7. Dimmable, automatic colour change, DMX 512+DMX decoder, DALI, 1-10 V controllable;

8. PVC mounting sleeve (included) helps easy installation.





Material specifications:

Housing: 12# Die-casting aluminum grey powder coated T=60-80µm.
Adhesion of ISO class 1/ASTM class 4B.
Front cover: Stainless steel SUS 316L#
Glass Step tempered white coating glass. T=8mm
Glass pressure capacity Full area=783kgs
Gasket Molding shaped seal
Driver
Constant current output
Single color LED=1-circuit output
RGB 3in1 LED=3-circuit output
Operating temperature: -20℃~40℃
Power cable:
H05RN-F 2X1.0mm² L=0.5m (low voltage)
H05RN-F 3X1. 0mm² L=0.5m (high voltage)
H05RN-F 4X0.75mm² L=0.5m (for RGB)
Mounting sleeve: PVC 014#









General Information:

Item No. Light source
Degree
(Θ 1 / 2 )
Input
voltage
(V)
Typical operating
current
(mA)
Typical
consumption
(w)
Typical
luminance
(lm)
IK rate
D2CAR0607


6×SMD

2835

120
24VDC Or
120 /240
24V=13
120V=8
240V=6
24V=0.3
120V=0.5
240V=0.8
Cool white=13.7
Warm white=11.8
09

 D2CAR0315

3×SMD
5050
RGB
3 in1
Full color
120 24VDC
R=21
G=21
B=21
1.5W 3.3 09

Note:
1. Single color: Warm White,Neutral White, Cool White,Red, Green, Blue and etc;
2. Specification and availability are subjected to change without notice







24VDC or 110~240VAC 0.5W Sqaure LED Inground Light Frosted Lens with Soft Beam 0

24VDC or 110~240VAC 0.5W Sqaure LED Inground Light Frosted Lens with Soft Beam 1

24VDC or 110~240VAC 0.5W Sqaure LED Inground Light Frosted Lens with Soft Beam 2





Dimensional Drawing(Units:mm):



24VDC or 110~240VAC 0.5W Sqaure LED Inground Light Frosted Lens with Soft Beam 3







B2CA,D2CA Series related LED underground Lights:

Item No. Light source
Degree
(Θ 1 / 2 )
Input
voltage
(V)
Typical operating
current (mA)
Typical
consumption
(w)
Typical
luminance
(lm)
IK rate
B2CAR0116
B2CAS0116
1×2W 30
24VDC Or
120 /240
24V=110
120V=48
240V=28
24V=2.6
120V=3.3
240V=3.3
Cool white=77
Warm white=65
09
B2CAR0118
B2CAS0118
1×3W
RGB 3in1
Full color
30 24VDC
R=38
G=53
B=54
3.5W 56 09
D2CAR0607
D2CAS0607
6×SMD3020 -
24VDC Or
120 /240
24V=13
120V=8
240V=6
24V=0.3
120V=0.5
240V=0.8
Cool white=13.7
Warm white=11.8
09
D2CAR0315
D2CAS0315
3×SMD5050
RGB 3in1
Full color
- 24VDC
R=21
G=21
B=21
1.5W 3.3 09
