Product Details:
|
| Item Type: | LED Landscape & Garden Spotlights | LED: | 1 Piece 2W Or 3W LED |
|---|---|---|---|
| Color: | Single Color Or RGB 3-in-1 Full Color | Power (W): | 24V=2.6 120V=2.4 240V=2.6 |
| Working Voltage: | 24VDC, Or 110 - 240VAC | Luminance (LM): | Cool White=149, Warm White=120 |
| Material: | Aluminum | Installation: | By Plastic Spike |
| IP Rating: | IP65 | Warranty: | 2 Years |
| High Light: | gu10 garden spike spotlights,led landscape flood lights |
||
B3AB0157, B3AB0106 (RGB) 24VDC or 110 - 240VAC 1 * 2W / 3W RGB LED Landscape Spotlights Black Body with Spike / Stake Mounting Outdoor Rated IP65
LED Landscape Spot light combines 2W or 3W high-intensity top grade high power LED, optical-grade PMMA lens and advanced heat dissipation mechanism anodized aluminum finish to provide exceptional photometric performance, energy efficiency and longevity. It offers Round base and spike these two Mounting ways for options. And the finish surface color available anodized silver or matted black painting. It is design IP65 rating in both interior and exterior environments use.
● IP Rating: IP65 for outdoor use;
● LED Source: 1piece 2W Or 3W High power LED;
● Input Voltage:24VDC standard (High voltage 110V/220VAC can be available);
● Emitting Color for options: Single Color and RGB Color;
● Mounting Base for options: Round base or Spike;
● Finish Surface Treatment: Aluminum Anodized or Matted black painting;
● Angle-position design: Angle adjustable freely design;
● optical-grade PMMA lens: efficiency≥85%;
● RGB version can be worked with DMX+DMX Decoder;
● Custom Made is available
Material specifications:
| Housing | Aluminum anodized finishing or powder painting |
| Lens | Optical lens, efficiency ≥ 85% |
| Glass | Tempered glass. T=3mm |
| Cable gland | Copper and nickel coated |
| Gasket | Tooling shaped seal |
| LED | TO type power LED for RGB, single color is Osram LED |
| PCB |
Excellent heat conductivity aluminum, coefficient of Heat Conductivity≥2.0w/mk |
| Driver | Constant current output |
| Operating temperature | -20℃~40℃ |
| Power cable | Constant current output Single color LED=1-circuit output RGB 3in1 LED =3-circuit output |
| Cable | H05RN-F 2X1.0mm² L=2m (low voltage) H05RN-F 3X0.75mm² L=2m (high voltage) H05RN-F 4X0.75mm² L=2m (for RGB) |
Techincal Specification:
| Item No. | Light source |
Degree
(Θ 1 / 2 )
|
Input
voltage
(V)
|
Typical
operating
current (mA)
|
Typical
consumption
(w)
|
Typical
luminance
(lm)
|
IK rate |
|
B3AB0157
(Ground Spike)
|
1×2W | 20 |
24VDC Or
120 /240
|
24V=110
120V=40
240V=26
|
24V=2.6
120V=2.4
240V=2.6
|
Cool white=149
Warm white=120
|
02 |
|
B3AB0106
(Ground Spike)
|
1×3W
RGB 3IN1
Full color
|
30 | 24VDC |
R=38
G=53
B=54
|
3.5 | 50 | 02 |
|
B3AM0157
(Round Base)
|
1×2W | 20 |
24VDC Or
120 /240
|
24V=110
120V=40
240V=26
|
24V=2.6
120V=2.4
240V=2.6
|
Cool white=149
Warm white=120
|
02 |
|
B3AM0106
(Round Base)
|
1×3W
RGB 3IN1
Full color
|
30 |
24VDC
240
|
R=38
G=53
B=54
|
3.5
|
50
|
02 |
