Product Details:
|
| Item Type: | High Power LED Garden Spotlight | LED: | 6pcs 2W Or 3W High Power LED |
|---|---|---|---|
| LED Brand: | Osram, Cree, Citizen, Edison, Prolight | Power (W): | 24V=13.2, 120V=10.5, 240V=10.5 |
| Luminance (LM): | Cool White=1004, Warm White=775 | Input Voltage: | 24VDC 120/240AC |
| Material: | Aluminum Lamp Body | IP Rating: | IP65 Waterproof |
| High Light: | led garden spotlights,led landscape flood lights |
||
FB3BQN0657, FB3BQN0618 (RGB) 24VDC 110 - 240VAC IP65 Waterproof 6 * 2W or 3W LED Landscape Spotlights with Round Base and Internal Driver
Features and Benefits:
1. 6pcs 2W or 3W Excellent brand Osram/ Cree/ CITIZEN and etc as its light source
2. Easy install by PVC spike or round base
4. high luminance output
5. with optional hood (order separately)
7. Lamp body made of aluminum helps fast heat dissipation.
8. LED color: Single color or RGB 3-in-1 Full color
Material specifications:
| Housing |
12 Die-casting grey powder coated aluminum .
T=60-80μm. Adhesion of ISO class 1/ASTM class 4B
|
| Glass | Tempered glass. T=4mm |
| Reflector | Optical Reflector efficiency≥90% |
| Cable gland | IP-68 PG-9 copper and nickel coated |
| Gasket | Molding shaped silicone double seal |
| LED | TO type power LED for RGB,single color is OSRAM Or Cree |
| PCB |
Excellent heat conductivity aluminum, coefficient of Heat Conductivity≥2.0w/mk |
| Driver |
Constant current output
Single color LED=1-circuit output
RGB 3in1 LED =3-circuit output
|
| Operating temperature | -20℃~40℃ |
| Power cable |
H05RN-F 2X1.0mm^2 L=2m (low voltage)
H05RN-F 3X1.0mm^2 L=2m (high voltage)
H05RN-F 4X0.75mm^2 L=2m (for RGB)
|
| Spike | PVC |
| Mounting base | Powder coated die-casting aluminum |
General Information:
| Item No. | Light source |
Degree
(Θ 1 / 2 )
|
Input
voltage
(V)
|
Typical operating
current
(mA)
|
Typical
consumption
(w)
|
Typical
luminance (lm)
|
IK rate |
| FB3BQN0657 | 6×2W | 20 |
24VDC Or
120 /240
|
24V=550
120V=89
240V=52
|
24V=13.2
120V=10.5
240V=10.5
|
Cool white=1004
Warm white=755
|
05 |
| FB3BQN0618 | 6×2W | 20 |
24VDC
|
R=210
G=260
B=260
|
17.5 |
365
|
05 |
Family Related Products:
| Item No. | Light source |
Degree
(Θ 1 / 2 )
|
Input
voltage
(V)
|
Typical operating
current
(mA)
|
Typical
consumption
(w)
|
Typical
luminance (lm)
|
IK rate |
| FB3BQB0657 | 6×2W | 20 |
24VDC Or
120 /240
|
24V=550
120V=89
240V=52
|
24V=13.2
120V=10.5
240V=10.5
|
Cool white=1004
Warm white=755
|
05 |
| FB3BQB0618 | 6×2W | 20 |
24VDC
|
R=210
G=260
B=260
|
17.5 |
365
|
05 |
| FB3BQN0657 | 6×2W | 20 |
24VDC Or
120 /240
|
24V=550
120V=89
240V=52
|
24V=13.2
120V=10.5
240V=10.5
|
Cool white=1004
Warm white=755
|
05 |
| FB3BQN0618 | 6×2W | 20 | 24VDC |
R=210
G=260
B=260
|
17.5 | 365 | 05 |
