Product Details:
|
Name: | 3 Step Dimming Led Shoebox Light | Power: | 240W And 320W |
---|---|---|---|
Input Voltage: | 110-277VAC | Light Efficiency: | 130LM/W |
Led Light Source: | SMD | Color Temperature(cct): | 3000K 4000K 5000K 6000K |
Mount Way: | Slip Fitter Mount Or Arm Mount | Beam Angle: | TypeII TypeIII TypeIV TypeV |
Photocell Sensor: | Optional Photocell Sensor | Application: | ROAD,parking Lot,square,Residential,site |
Lamp Body Material: | Die-casing Aluminum Housing | Working Lifetime(hour): | 50000 |
Warranty: | 3 Or 5 Years Warranty | ||
High Light: | led shoebox pole light,led parking lot light |
Technical Information:
Note:
model suffix can be added X, X can be blank, A, B or C.
A means no Photocell sensor.
B means with Photocell sensor
C means motion sensor.
Power | 240W | 320W |
Model | CL-LD-240W-S-X | LD-320W-S-X |
Luminous Flux | 26000lm | 39000lm |
Replacement | HPS 600-700W | HPS1000W |
ETL DLC | YES | |
Light Source | SMD LED | |
Luminous Efficacy | 130lm/w | |
Operation Temp | -40 to +45℃ | |
CCT | 2700K SW / 3000K WW / 4100K NW / 5000K DW / 5700K CW | |
CRI | >80 | |
Life Span | 50,000 hours at 25℃ | |
Voltage | 100-277VAC/50-60Hz, 200-480VAC/50-60Hz | |
Driver | Conventional power supply ,Time control power supply ,3 in 1 dimming power supply | |
With sensor | Timmer Control,Motion Sensor,Photocell Sensor,3 in 1 dimming, | |
Wifi Zigbee Connect,photocell+timmer control,3 step dimming, | ||
GPRS,3G/4G,Blue tooth,PLC and smart motion sensor. | ||
Microwave sensor | Detect human- brightness 100%, microwave sensitivity 75%, hold time 5 minutes, | |
default setting | start illumination 50LUX, continuous brightness 30%, the duration of 30 minutes | |
Beam Angle | TYPE Ⅲ-M ,TYPE Ⅳ-M (Type 2 and Type 5 optional) | |
PF | >0.95 | |
IP | 65 | |
Warranty | 3/5Years | |
Installation way | Slipfitter Mount | |
Lamp Paint | Bronze | |
Photocell | NO (Optional) |
Optional Accessories:
