Recessed Led Outdoor Step Lights
  • name
  • name
  • name
  • name

Recessed Led Outdoor Step Lights

MOQ: 10PCS
Standard Packaging: Inner Box and Outer carton
Delivery Period: 5 - 15 days
Payment Method: T/T, L/C, Western Union, MoneyGram
Supply Capacity: 100,000 PCS per month
Detail Information
Product Description
Detail Information
Place of Origin
Guangdong China
Brand Name
COMI LIGHTING
Certification
CE, ROHS
Model Number
D1G1807
Item Type:
LED Recessed Stair & Wall Lights
Input Voltage:
110 - 240VAC
LED:
SMD2835 LED
Power (W):
120V=1.8, 240V=2.0
Luminance (LM):
Cool White=59 D1G1807, Warm White=48
Material:
Aluminum
Installation:
By PVC Mounting Sleeve
IP And IK Rating:
IP65 And IK10
Minimum Order Quantity:
10PCS
Packaging Details:
Inner Box and Outer carton
Delivery Time:
5 - 15 days
Payment Terms:
T/T, L/C, Western Union, MoneyGram
Supply Ability:
100,000 PCS per month
Highlight:

round step lights

,

led outdoor stair lights

Product Description

D1G1807 110 - 240VAC 2W 2835SMD LED Recessed Step & Stair & Wall Lights Included Mounting Sleeve







Features:

1. The silver painting with special treatment of the surface stays after the salt-spray test with 7% concentration in 200 hours.
2. With IT class LED as light source, it remains 60% luminous flux after 20,000 hours when operating under t normal temperature.
3. 2W power consumption for the whole fitting meets the energy-saving requirements.





Material specifications:

Housing: 12# Die-casting aluminum grey powder coated T=60-80µm.
Adhesion of ISO class 1/ASTM class 4B.
Front cover: 12# Die-casting aluminum PT877U powder coated T=20-30µm.
Adhesion of ISO class 1/ASTM class 4B
Cable gland: IP-67 copper and nickel coated
Gasket: Molding shaped silicone seal
LED: SMD3528 type power LED
Driver: Constant current output
Operating temperature: -20℃~40℃
Power cable: H05RN-F 3X1.0mm^2 L=0.5m
Mounting sleeve: D1G1807: Zinc-coated steel 136#
D1I2007,D1I2407:PVC 081#





Technical Information:

Item No. Light source
Degree
(Θ 1 / 2 )
Input
voltage(V)
Typical operating
current (mA)
Typical
consumption
(w)
Typical
luminance
(lm)
 IK rate
D1G1807 18×SMD3528 120 110/240VAC
120V=26
240V=18
120V=1.8
240V=2.0
Cool white=59
Warm white=48
 10







Dimensional Drawing(mm):



Recessed Led Outdoor Step Lights 0







Recessed Led Outdoor Step Lights 1









Family Related Products:



Recessed Led Outdoor Step Lights 2Recessed Led Outdoor Step Lights 3Recessed Led Outdoor Step Lights 4

                D1G1807                                    D1I2007                                        D1I2407





Recessed Led Outdoor Step Lights 5





General Information:

Item No. Light source
Degree
(Θ 1 / 2 )
Input
voltage(V)
Typical operating
current (mA)
Typical
consumption
(w)
Typical
luminance
(lm)
 IK rate
D1G1807 18×SMD3528 120 110/240VAC
120V=26
240V=18
120V=1.8
240V=2.0
Cool white=59
Warm white=48
 10
D1I2007 20×SMD3528 120 110/240VAC
120V=38
240V=23
120V=2.3
240V=2.5
Cool white=66
Warm white=53
 10
D1I2407 20×SMD3528 120 110/240VAC
120V=36
240V=28
120V=2.4
240V=3.0
Cool white=80
Warm white=68
 10

Note:
1. Color options: Warm White, Neutral White, Cool White, Red, Green, Blue and etc;
2. Specification and availability are subjected to change without notice.



Tags:

round step lights,

recessed led stair lights,

led outdoor stair lights
